Product Description
Package
| Package | Product | Vces(V) | Ic(A) | VCE(sat)(V) | Configuration | typical value @Tj=25℃ | ||
| VF(V) | Eon(mJ) | Eoff(mJ) | ||||||
| DriveP3 | PMD50M120S1P_T3 | 1200 | 50 | 1.60 | PIM | 1.90 | 3.2 | 2.6 |
| PMD75M120S1P_T3 | 1200 | 75 | 1.60 | PIM | 1.90 | 3.1 | 5.0 | |
| PMD75M120S1P_T4 | 1200 | 75 | 1.60 | PIM | 1.90 | 3.1 | 5.0 | |
| PMD100M120S1P_T4 | 1200 | 100 | 1.70 | PIM | 1.90 | 3.8 | 5.3 | |
| PMD150M120S1P_T4 | 1200 | 150 | 1.70 | PIM | 1.90 | 5.2 | 9.1 | |
| PMD100TA120S1P_T4 | 1200 | 100 | 1.90 | PIM | 2.00 | 4.9 | 4.6 | |
| PMD150TA120S1P_T4 | 1200 | 150 | 1.90 | PIM | 2.00 | 6.5 | 7.0 | |
